Capacity: 100 ton
Model Number:CLP | CLSG | CLRG | CLL |
RCS | RC | RSM | RRH | RCH
Stroke: 16-300mm
Max.pressure: 700bar /10000psi
Weight: 15.5-106KG
Oil capacity:246 - 4620(cm3)
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
Sample:Contact us for free samples
Capacity: 100 ton
Model Number:CLP | CLSG | CLRG | CLL |
RCS | RC | RSM | RRH | RCH
Stroke: 16-300mm
Max.pressure: 700bar /10000psi
Weight: 15.5-106KG
Oil capacity:246 - 4620(cm3)
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
| Model Number | Cylinder Capacity ton(KN) | Stroke(mm) | Oil Capacity(cm³) | Weight(kg) |
| CLP | 100(1027) | 50 | 734 | 27 |
| CLSG | 100(1077) | 50/100/150/200/300 | 770/1540/2310/3080/4620 | 16 |
| CLRG | 100 | 50/100/150/200/300 | 770-4620/377-2262 | 24 |
| CLL | 100(887) | 16 | 246 | 15.5 |
| RCS | 100(887) | 57 | 877 | 24.5 |
| RC | 100(933) | 168/260 | 2229/3449 | 59/72 |
| RSM | 100(887) | 16 | 246 | 15.5 |
| RRH | 100 | 38/76/153/257 | 514-3477/346-2341 | 33/61/79/106 |
| RCH | 100(947) | 76 | 1028 | 63.5 |
100 Ton CLP Series Single-Acting Low Profile Lock-Nut Hydraulic Cylinder
- Single-acting, load return.
- Low profile design for narrow applications.
- Special painted surface for corrosion resistance.
- Lock nut ensures long-term load holding safety.
- Quick couplings and dust-proof cap included.
- Overflow port limits stroke.
- Removable hardened grooved saddles.
- Customizable with special requirements.
- Integral tilt saddles with maximum tilt angles up to 4°.
- Compatible with SAIVS high-quality high-pressure hoses.
- CLL-Series Lock-Nut Cylinders available for longer stroke applications.
100 Ton CLSG Series Single-Acting High Tonnage Hydraulic Cylinders
- Single acting, loads return.
- Chrome plated steel plungers.
- Plunger wiper reduces contamination.
- Exclusive guide Ring absorbs eccentric loading.
- Special painted surface for corrosion resistance.
- Easy fixturing with base mounting holes.
- Quick couplings and dust-proof cap included.
- Removable hardened saddles protect plunger.
100 Ton CLRG Series Double-Acting High Tonnage Cylinders Lift Jack
- Double acting, positive retraction.
- Chrome plated steel plungers.
- Plunger wiper reduces contamination.
- Exclusive guide Ring absorbs eccentric loading.
- Built-in safety valve prevents over-pressurization.
- Special painted surface for corrosion resistance.
- Easy fixturing with base mounting holes.
- Quick couplings and dust-proof cap included.
- Removable hardened saddles protect plunger.
100 Ton CLL Series Single-Acting High Tonnage Lock-Nut Hydraulic Cylinders
- Single acting, loads return.
- Special painted surface for corrosion resistance.
- Lock nut ensures load holding safety.
- Quick couplings and dust-proof cap included.
- Overflow port limits stroke.
- Exclusive guide Ring absorbs eccentric loading.
- Removable hardened saddles protect plunger.
- Mechanical lock nut cylinder can be customized.
- Top and side mounted lifting eyes.
100 Ton RCS Series Single-acting Low Height Hydraulic Cylinders Jack
- Single-acting, spring return.
- Low profile design for narrow applications.
- Special painted surface for corrosion resistance.
- Two plunger threads on grooved end.
- Quick couplings and dust-proof cap included.
- Handles on some models for easy carrying.
- No saddle required with grooved end.
- Customizable with special requirements.
100 Ton RC Seires Single-Acting Hydraulic Cylinders
- Single-acting, high strength spring return.
- Exclusive guide Ring absorbs eccentric loading.
- Special painted surface for corrosion resistance.
- Easy fixturing with collar threads and base mounting holes.
- Quick coupling and dust cap included.
- Removable hardened grooved saddles.
- Customizable with special requirements.
100 Ton RSM Series Single-Acting Low Flat Hydraulic Ram
- Single-acting, spring return.
- Flat design for confined spaces.
- No saddle required with grooved end.
- Two plunger threads on grooved end.
- Special painted surface for corrosion resistance.
- Handles on some models for easy carrying.
- Quick coupling and dust cap included.
- Customizable with special requirements.
100 Ton RRH Series Double-Acting Hollow Cylinders Jack
- Double-acting cylinder for fast retraction.
- Hollow plunger design for both pull and push forces.
- Dual dust-proof ring structure maintains internal cleanliness.
- Exclusive guide ring absorbs eccentric loading, reducing wear.
- Built-in safety valve prevents over pressurization.
- Special painted surface for corrosion resistance.
- Easy fixturing with collar threads and base mounting holes.
- Quick couplings and dust-proof cap included.
- Floating center tube for extended product life.
- Customizable with special requirements.
100 Ton RCH Series Single-Acting Hollow Cylinders
- Single-acting, high strength spring return.
- Hollow plunger design for both pull and push forces.
- Dual dust-proof ring structure maintains internal cleanliness.
- Exclusive guide ring absorbs eccentric loading, reducing wear.
- Special painted surface for corrosion resistance.
- Easy fixturing with collar threads and base mounting holes.
- Quick couplings and dust-proof cap included.
- Floating center tube for extended product life.
- Customizable with special requirements.
- Compatible with SAIVS high-quality high-pressure hoses.
- Pressure Display Unit (optional) on pressure gauges.
- Suitable pump selection for optimum combination.
